Driver de LED à Courant Constant - 1 Sortie - 350 mA - 25 W

Driver de LED à Courant Constant - 1 Sortie - 350 mA - 25 W

PLM-25E-350
Dépêchez-vous ! Seulement 26 articles restants en stock.
32,34 €
TTC
  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

PLM-25 is a 25 W economical AC/DC LED power supply series. Incorporating a built-in active PFC design, PLM-25 provides a high power factor value greater than 0.9. In addition, with the low no load power consumption below 0.5 W, and the setup time less than 500ms, PLM-25 is complied with the ERP regulation required by European Union for lighting fixtures.

PLM-25 is a class II (without FG pin) power unit housed with the UL 94V-0 rated flame retardant plastic case. The I/O terminals are designed with screw-less clamp style terminal block that greatly simplifies the wiring installation. Two types of models with different input voltage range are offered: PLM-25 series, which operates from 110-295 VAC, and PLM-25E series, which operates from 180-295 VAC. These two series are both constant current output design, supplying models with the current of 350 mA, 500 mA, 700 mA and 1050 mA, respectively.

Caractéristiques

  • 230 VCA ou plage complète (max. 295 VCA)
  • fonction PFC active intégrée
  • courant constant
  • protections: court-circuit
  • refroidissement par convection naturelle
  • boîtier en plastique complètement isolé
  • classe II, sans mise à la terre
  • classe 2 (pour PLM-25-500/700/1050)
  • consommation à vide : <0.5 W
  • haute fiabilité, économique

Spécifications

  • Caractéristiques physiques
  • Couleur primaire: Blanc
  • Couleurs supplémentaires: Bleu
  • Profondeur du produit: 145 mm
  • Hauteur du produit: 22 mm
  • Largeur du produit: 38 mm
  • Poids Produit: 110 g
  • Propriétés électriques
  • Indice IP: IP30
  • Puissance de sortie nominale: 25.2 W
  • Courant de sortie nominal: 350 mA
  • Courant nominal d'entrée: 0.15 A
  • Tension de sortie maximale nominale VDC: 72 V
  • Tension de sortie minimale nominale VDC: 42 V
  • Tension d'entrée minimale nominale VAC: 180 V
  • Tension d'entrée maximale nominale VAC: 295 V
  • Tension d'entrée VDC 1: 254 V
  • Tension d'entrée nominale VDC 2: 417 V
  • Éclairage et propriétés optiques
  • Série Pilote LED: PLM
  • Caractéristiques techniques et performances
  • Type de technologie: Mode de courant constant
  • Dimmable: Non
  • Type de gradateur: Pas de variation
  • Nombre points de sorties: 1
  • Type de boîtier: Fermé
  • Conformité & Certification
  • GPSR responsable - Nom du contact: TELEREX
  • GPSR responsable - Adresse: Uilenbaan 90 Unit 8, 2160, WOMMELGEM, Belgium
  • GPSR Responsable - Site web: http://www.telerex-europe.com
  • Responsable GPSR - Email: info@telerex-europe.com
  • GPSR responsable - Numéro de téléphone: 03/326.40.00
: PLM-25E-350
Dépêchez-vous ! Seulement 26 articles restants en stock.

Fiche technique

Packaging
Box (Carton)

Références spécifiques

EAN-13
8720207879736
